Titanium Heat Exchanger D-TWT 35 - 42 kW
Titanium Heat Exchanger D-TWT 35 - 42 kW
Description
The D-TWT titanium heat exchanger is a spiral-design heat exchanger made of titanium alloy. Read moreProduct code: 060110
-
Thermal Titanium Heat Exchanger D-TWT 35 - 42 kW
The D-TWT thermal titanium heat exchanger is a spiral-design heat exchanger made of titanium alloy. Titanium is one of the most durable materials, which is why these heat exchangers can be used, for example, with salt water or other aggressive media. Thanks to their design, the heat exchangers are specially engineered for heating pool water, water in whirlpools and spas, or for underfloor heating. The exchanger design is optimized to limit flow so that heat transfer is maximized while pressure in the heating system is minimized. The exchanger is also suitable for saltwater pools.
Advantages
- Spiral design made of titanium alloy
- High quality
- Improved energy efficiency
- Chemical resistance
- Must be integrated directly into the pool water circuit
Use:
- pools
- whirlpools
Power kW
Output at 90°C 42 kW Output at 80°C 36 kW Output at 70°C 30 kW Output at 60°C 24 kW Output at 50°C 18 kW
Package Contents
- Heat exchanger body
- Stainless steel mounting clamps
Technical Parameters
- Output: 35 - 42 kW
- Flow rate (primary): 2 m3 / h
- Pressure drop (primary): 0.18 bar
- Flow rate (secondary): 10 m3 / h
- Pressure drop (secondary): 0.1 bar
- For pools up to: 35 - 40 m3
- Max. pressure on heating side: 10 bar
- Max. pressure on pool side: 3 bar
- Max. temperature: 90°C
- Weight: 2 kg
-
