Counter-current pump Espa Nadorself 400T - 66 m3/h - 400 V
Counter-current pump Espa Nadorself 400T - 66 m3/h - 400 V
Description
The ESPA Nadorself pump represents the technological pinnacle in pool hydraulics, with its primary purpose being to power both commercial and private counter-current systems, hydromassage jets, and attractions ... Read more-
Espa Nadorself 400T Counter-Current Pump - 66 m3/h - 400 V
The Espa Nadorself pump represents the technological pinnacle in pool hydraulics, and its primary purpose is to power both commercial and private counter-current systems, hydromassage jets, and attractions requiring an enormous water flow. Unlike standard filtration pumps, which work with a smaller volume of water under higher pressure and are equipped with a prefilter to capture coarse debris, this unit operates on the principle of massive circulation without pre-filtration. This allows it to instantly move a huge amount of water and create a strong, stable, and wide current that can simulate a river flow directly in the pool. As a result, even a smaller home pool can be transformed into a full-fledged sports and rehabilitation facility, where swimmers can train without having to constantly turn around at the end of the pool. Its high level of electrical protection and special insulation class ensure that the pump can safely withstand the extremely humid environment of technical rooms. The integrated thermal protection continuously monitors the winding temperature and, in the event of overheating risk, automatically disconnects the unit, protecting it from fatal damage and restoring operation once it has cooled down. The entire pump body, together with the internal diffuser and impeller, is injection-molded from an advanced technopolymer reinforced with glass fibers for maximum mechanical strength. The motor shaft is made of premium stainless steel, and highly durable mechanical seal ensures perfect separation of the hydraulic and electrical parts. The hydraulic design itself, with an extra-large connection thread diameter, minimizes friction and pressure losses, which in practice means the pump can move more than fifty cubic meters of water in a single hour while maintaining high energy efficiency. The unit also features self-priming capability, but for ideal operating conditions and immediate current start-up, installation below the pool water level is recommended.
Advantages:
- High water flow: Ideal for creating a strong and smooth current for stationary swimming.
- Prefilter-free design: Enables direct and massive water transfer without hydraulic losses.
- Top-quality material resistance: Glass-fiber-reinforced technopolymer and stainless steel guarantee long service life and resistance to pool chemicals and salt water.
- Integrated thermal protection: Protects the motor from burnout by automatically switching it off when overheated and turning it back on after cooling.
- High electrical protection rating: safely withstands the extremely humid environment of technical rooms
- Self-priming capability: Flexibility in installation (although the ideal position remains below the water level).
Material
Pump body, impeller, diffuser, suction and discharge in technopolymer.
- Pump shaft in AISI 431
- Mechanical seal made of aluminum and graphite
- Motor housing made of aluminum
- O-rings made of NBR / EPDM
Package Contents
- pump
- connection fittings
- seals
- manual
Technical Specifications
- Voltage: 400 V
- Suction / discharge connection - glued: 75 / 75 mm
- Protection rating: IPX5
- Pump shaft: AISI 431
- Insulation class: F
- Power: 3 kW
- Speed: 2900 rpm
- Flow rate: 66 m3/h
- Input power: 3.8 kW
- Self-priming: up to 4 m
- Pump installation: must be below water level
- Maximum water temperature: 40°C
- For salt water up to 7 g/l (< 0.7%): Yes
- 2-pole asynchronous single-phase motor with built-in thermal protection
- Continuous operation
- Weight: 28 kg
-
