Counter-current Pump New BCC 300M - 66 m3/h - 230 V

New

Counter-current Pump New BCC 300M - 66 m3/h - 230 V

Description

Especially suitable for counter-current systems, it can also be used as a circulation pump for water attractions (spouts, etc.). The pump is suitable for use in pools with fresh, salt, and seawater. Read more

Product code: 300773

Description
Related products

Counter-Current Pump New BCC 300M - 66 m3 / h - 230 V

Counter-current system for pools is a very good choice if you want to make full use of your pool. Swimming is very popular and healthy, so it would be a shame not to use your pool for this sport.
Counter-current systems are mainly designed for smaller pools (approx. 5-10 m long with a minimum width of 2.5 m), but they will certainly also find use in larger pools.
The main division of counter-current systems is based on the installation method: suspended and built-in. Suspended counter-current systems are an additional solution or are used for above-ground pools. Built-in counter-current systems can be chosen for any type of pool and are significantly cheaper than buying a suspended unit separately.
The output of counter-current systems is usually stated in m³ / h.

NEWBCC pumps are characterized by a high-quality polypropylene construction with a 30% glass fiber content. The NEWBCC pump can also be used for saltwater and seawater pools.

Package Contents

pump
75 mm connecting piping

Technical Parameters

Voltage: 230 V
Suction / discharge connection - glued: 75 / 75 mm
Motor protection: IP 55
Power: 2.2 kW
Speed: 2850 rpm
Flow rate: 66 m³ / h
Input power: 2.4 kW
Noise level: 74-79 dB
For seawater: Yes
Impeller material: Plastic - Noryl
Max. operating pressure: 3 bar
For saltwater up to 5 g / l (<0.5%): Yes
Pump installation: must be below water level
Maximum water temperature: 60°C
Use: Suitable for both fresh and saltwater with a salt concentration of up to 5 g/l, as well as for seawater with a salt concentration above 5 g/l
For saltwater up to 5 g / l ( < 0.5 % ): Yes
For seawater above 5 g/l (>0.5%): Yes
Weight: 19.915 kg
