VA Remote Switching, 4-channel + 2 key fobs
VA Remote Switching, 4-channel + 2 key fobs
Description
This device is suitable, for example, for improving ease of operation, or in places where it is not possible, or is difficult, to switch electrical appliances on and off using a standard switch with a ... Read more
Product code: 520RCD4TX
-
VA Remote Switching 4-Channel + 2 Key Fobs
Radio Control for Electrical Devices
This device is suitable, for example, for improved operating convenience, or where it is not possible, or is difficult, to switch electrical appliances using a standard switch with a mechanical contact. With this switching system, it is possible to switch 4 relays with switching contacts and one normally closed contact. Range under ideal conditions is up to 80 meters. A greater distance can be achieved by connecting an external antenna with a coaxial cable.
Remotely Controlled Electronic Switching System
- can be used to switch lights, pump motors, etc.
- includes: switching module + two control key fobs
Technical Parameters
- Product type: Radio control for electrical equipment
- Supply voltage: 230 V AC, 50 Hz
- Power consumption: 1 / 1.5 VA
- Relay contact rating: (230 V / 6 A) AC, resistive load
- Dimensions: DIN (53 x 90 x 62) mm
- Degree of protection: DIN IP 20
- Protection class: II (double insulation)
- Overvoltage category: II
- Operating ambient temperature: (-10~+50) °C
- Remote control (RC): 433.92 MHz; range 80 m (open space)
- Number of channels: 2
- Key fob: Yes - 4 pieces
- Weight: 0.244 kg
-
