Speck Badu Resort 110 Pool Pump - 110 m³/h, 400/690 V, 6.35 kW
Speck Badu Resort 110 Pool Pump - 110 m³/h, 400/690 V, 6.35 kW
Description
The self-priming BADU RESORT pump is suitable for public facilities such as wellness centers or water attractions. It is suitable for both fresh water and salt water with a salt concentration of up to ... Read more
Product code: 573RES110N
-
Speck Badu Resort 110 Pool Pump - 110 m3/h, 400/690 V, 6.35 kW
The self-priming BADU RESORT pump is suitable for use in semi-public and public facilities such as wellness centers. It can also be used as a pump for water attractions. The housing is made of plastic reinforced with glass fibers. These pumps offer a flow rate of 30–110 m3/h and an output of 1.5–5.5 kW.
The pump can be used for salt water with a salt concentration of 0.5%, i.e. 5 g/l. For higher concentrations, a pump marked “AK” must be used.
The pump can be installed a maximum of 3 m above/below the water level.
The motor/pump shaft has no contact with the pool water, ensuring complete electrical separation.
Package Contents
- Badu Resort pump
- tightening wrench
- debris basket
- nut and lid with gasket
- connection fittings
Power cable is not included!
Pump Wiring
Technical Specifications
- Product type: Filter pump
- Motor protection: IP55
- Power: 5.5 kW
- Speed: 2840 rpm
- Flow rate: 110 m3 /h
- Input power: 6.35 kW
- Voltage: 400/690 V
- Suction / discharge connection - glued: 110/110 mm
- Self-priming: Yes
- Impeller material: Plastic
- Max. operating temperature: 60 °C
- Max. operating pressure: 2.5 bar
- Use: Suitable for fresh and salt water with a salt concentration up to 5 g/l
- For salt water up to 5 g/l (<0.5%): Yes
- For salt water above 5 g/l (>0.5%): AK version
- Weight: 41 kg
Spare Parts List
You can find the complete list of spare parts here:
-
