Pool pump DAB Euroswim 200T, 28 m³/h, H=10 m, 2.0 HP, 400 V
Pool pump DAB Euroswim 200T, 28 m³/h, H=10 m, 2.0 HP, 400 V
Description
This highly efficient self-priming pump with exceptionally quiet operation (53 - 64 dBA) is equipped with a built-in high-capacity pre-filter, whose design significantly increases filtration capacity and ... Read more-
Pool Pump DAB Euroswim 200T, 28 m3 / h, H=10 m, 2.0 HP, 400 V
This highly efficient self-priming pump with exceptionally quiet operation (53 - 64 dBA) is equipped with a built-in high-capacity prefilter, whose design significantly increases filtration capacity and minimizes maintenance caused by clogging. The unit is primarily designed for water circulation and filtration in residential pools, but it can also be used to a limited extent in agriculture or industry. Single-phase and three-phase versions are available, with output from 0.5 HP to 3 HP. The pump reliably handles clean or slightly contaminated water, and it can also cope without problems with water containing high levels of chlorine, bromine, chlorine-free PHMB disinfection (polyhexamethylene biguanide), water treated by salt electrolysis, or even seawater. Thanks to its versatile design, it can be permanently installed or used as a portable unit. The pump’s high durability is guaranteed by premium materials. The pump housing and filter basket are made of glass-fiber-reinforced technopolymer, while the diffuser is made of reinforced technopolymer. The transparent prefilter lid is made of chemically resistant polycarbonate, allowing constant monitoring of debris buildup. Tightness is ensured by a mechanical seal made of a combination of carbon, aluminum, NBR rubber, and AISI 316 stainless steel, complemented by NBR O-rings. All standard threaded fasteners and reinforcing rings are also made of corrosion-resistant AISI 316 steel. A major practical advantage is the drain and fill plugs, which can be easily removed and replaced without any tools. The pump is driven by a fully waterproof asynchronous two-pole motor for continuous duty (S1). Its cast aluminum body is protected by an electrophoretic coating that effectively prevents oxidation even in the most aggressive environments. For maximum safety and stability, the single-phase version is equipped with built-in thermal and overcurrent protection, along with a PSC (Permanent Split Capacitor) capacitor safely located directly in the motor terminal box.
Advantages
- High efficiency and self-priming capability - ensures fast and effective pool water circulation.
- Exceptionally quiet operation - with noise levels of only 53 to 64 dBA, it ranks among the quietest in its class.
- Large-capacity prefilter - captures more dirt, significantly extending cleaning intervals and reducing maintenance requirements.
- Exceptional chemical resistance - easily handles chlorine, bromine, chlorine-free chemicals (PHMB), salt water (electrolysis), and seawater.
- Premium anti-corrosion materials - components made of glass-fiber-reinforced technopolymer and AISI 316 stainless steel ensure extreme mechanical durability and long service life.
- Motor protected against oxidation - the aluminum motor body has a special electrophoretic finish that protects it against corrosion even in humid and aggressive environments.
- Easy tool-free maintenance - the drain and fill plugs can be easily unscrewed by hand.
- High safety - single-phase versions have built-in thermal and overcurrent protection.
- Flexible installation - the pump can be firmly anchored in the system or used as a mobile, portable unit.
- Wide range of versions - single-phase and three-phase models are available with output from 0.5 HP to 3 HP to suit your pool’s needs.
Package Contents
- Pool pump
- Connection fittings
- Transparent prefilter lid with sealing O-ring
- Internal filter basket
- Instruction manual
Technical Specifications
- Product type: Self-priming pump
- Output: 28 m3 / h
- Voltage: 3 x 230 - 400 V - 50 Hz
- Motor shaft: AISI 416 stainless steel
- Metal components and screws: AISI 316 stainless steel
- Protection rating: IP55
- Insulation class: F
- Power input of the pump: 1800 W
- Motor power: 2 HP
- Head: 10 m
- Maximum liquid temperature: up to +60 °C
- Maximum ambient temperature: +50 °C
- Maximum operating pressure: 2.5 bar
- Current: 5.9 / 3.4 A
- Connection: 63 mm
- Noise level: 53 - 64 dBA
- Suitable for: fresh, salt, and seawater
- Self-priming: Yes
- Weight: 21 kg
-
