Fairland Norm Super Mini Cube Heat Pump - 3 kW for up to 15 m³
Fairland Norm Super Mini Cube Heat Pump - 3 kW for up to 15 m³
Description
Norm Mini Cube is suitable for small pools and whirlpools. Read more
-
Fairland Norm Super Mini Cube Heat Pump - 3 kW for up to 15 m3
Thanks to its compact size and output, the Norm Super Mini Cube is ideal for use with small private pools or whirlpools. Its compact design and quiet operation make it the perfect choice for those looking for a reliable unit to maintain a pleasant water temperature. For connection to 32 and 38 mm hoses, first install at least 0.5 m of pipe, and only then use the connector and hose tail to attach the hoses. Always connect the heat pump via a bypass, i.e. a three-valve bypass, so you can regulate the water flow through the pump. At lower flow rates, heat is transferred to the pool water more efficiently. Energy savings - operating costs are up to twice as low compared to a standard heat pump, with no "cold starts" that affect service life. The overall installation is not complicated in any way - all joints are bonded together with PVC adhesive (e.g. Tangit).
- C.O.P. 4.84
- Can also be controlled via Bluetooth
- Operating temperature: 10 - 43 °C
- Connection: - Hose tail 32 / 38 mm
- Union fitting 32 - 50 mm - For small pools and hot tubs
Connection to the Filtration Circuit
For connection to the filtration circuit, the heat pump is supplied with union fittings for bonding 50 mm PVC pipe. For connection to 32 and 38 mm hoses, first install at least 0.5 m of pipe, and only then use the connector and hose tail to attach the hoses.
Always connect the heat pump via a bypass, i.e. a three-valve bypass, so you can regulate the water flow through the pump. At lower flow rates, heat is transferred to the pool water more efficiently. The optimal water flow through the heat pump is 0.7 m3 / h. Even a smaller sand filter system can handle this flow rate.
The overall installation is not complicated in any way - all joints are bonded together with PVC adhesive (e.g. Tangit).
Package Contents
- Heat pump
- Power cable
- Connection fittings
- Manual
Technical Specifications
- Product type: Heat pump
- Unit dimensions (w / l / h): 420 x 350 x 380 mm
- Color: white / gray
- Heating output: 3 kW
- Cooling: no
- Recommended pool volume: max. 15 m3
- Recommended water flow: 0.7 m3 / h
- Connection: 32 / 38 mm
- Rated input: 0.62 W
- Refrigerant used: R32
- Voltage: 230 V
- Efficiency: 4.84 C.O.P.
- Operating temperature: +10 to +43 °C
- Energy saving: yes
- Easy installation: yes
- Weight: 20 kg
-
