Oase Aquarius Eco Expert 20000 / 12 V - fountain pump
Oase Aquarius Eco Expert 20000 / 12 V - fountain pump
Description
The Aquarius Universal Eco Expert 20000, 12 V fountain pump is a German pump specially developed for swimming ponds where safe 12 V technology is required. Read more
-
Oase Aquarius Eco Expert 20000 / 12 V - fountain pump
The Aquarius Universal Eco Expert 20000, 12 V fountain pump is a German pump specially developed for swimming ponds where safe 12 V technology is required. It features manual flow or discharge adjustment, can be installed down to -20 °C, and is suitable for both wet installation and dry chamber installation. The intake basket is made of stainless steel. It comes with an adapter for connecting 1" and 1 1/2" fountain nozzles. This is an energy-efficient fountain pump that uses 50% less energy than the previous model. It also includes protection against dry running and pump blockage. The pump is also suitable for long-term use in seawater. The pump is equipped with EFC function - protection against dry running and detection of a blocked rotor, EGC - control via app, and DFC - an optional function for activating a dynamic fountain effect. Energy consumption is reduced by up to 50% compared to previous models. To use the EGC functions, an InScenio EGC Home / Cloud, InScenio FM-Master EGC Home / Cloud, InScenio FM-Master WiFi EGC, or InScenio FM-Master WiFi version 2.0 or newer controller is required.
Advantages:
- powerful pump for high and wide water effects
- pump powered via a power supply unit converting 230 V to safe 12 V
- easy water flow adjustment
- extremely quiet operation
- integrated thermal protection
- energy-efficient thanks to low power consumption
- frost-resistant down to -20 °C
- high-quality stainless steel construction
- electronic water control with optional accessories
- fine housing grille prevents the nozzle from clogging with dirt
- removable base for installation even in the tightest spaces
- overload and dry-run protection
- installation in water or dry
- the stated maximum discharge indicates the height at which the water appears but does not flow
Details
Pump maintenance
- for long-term satisfaction with your purchased pump, we recommend regular maintenance
- before starting maintenance, always disconnect it from the power outlet
- regularly check the pond pump and intake basket for faults or blockages, at least once a month
- every 2 to 3 months, disassemble the intake cover, unscrew the screws, remove the impeller and carefully take out the rotor; it is only inserted
- clean the individual parts with warm water and remove any limescale deposits if present
- reassemble in reverse order. Do not lift the pump by the power cable
Technical parameters
- Dimensions (L x W x H): 490 x 215 x 235 mm
- Rated voltage (primary, secondary): 220 - 240 V / 50 - 60 Hz, 12 V / DC
- Power consumption: 30 - 240 W
- Cable length: 8 + 2.5 m
- Weight: 15.10 kg
- Warranty: 3 + 2 years
- Max. flow rate: 333 l / min.
- Max. flow rate: 20000 l / h
- Max. discharge head: 6.60 m
- Discharge connection DN - (inner diameter): 50 mm
- Suction connection DN - (inner diameter): 50 mm
- Hose connection DN - (inner diameter): 38 / 50 mm - 1 ½", 2"
- Pump filter area: 1000 cm2
- EGC connection: yes
- Electronic control possible: yes
- Installation type: in water, dry installation
Features
Aquarius Eco Expert 12 V fountain pump
Oase pump comparison table
Spare parts list
You can find the complete spare parts list here:
Spare parts for Oase Aquarius Eco Expert 20000 / 12 V
-
